Max. rated lifting capacity

kg

300000

Max. lift height of main boom

m

80

Max. lift height of jib
(The parameters do not include deflection of main boom and jib. The value in the brackets is the value with extensions installed)

m

112

Max. hoist rope speed (Main winch)

m/min

113

Max. hoist rope speed (Auxiliary winch)

m/min

56

Boom derricking up time

s

100

Boom extending time

min

18

slewing speed

r/min

0 ~ 1.3

Max. driving speed

km/h

72

Max. gradeability

%

50

Min. turning diameter

m

24

Min. ground clearance

mm

355

Fuel consumption per hundred kilometers

L

85

Deadweight in driving condition

kg

72000

Axles load

kg

12000

Overall dimensions (L×W×H)

mm

17752×3000×4000

Outrigger spread (L)

m

8.8

 Outrigger spread (W)

m

8.8

Main boom length

mm

15.4 ~ 80

Boom angle

°

-0.6 ~ 82

Light Jib length

m

12 ~ 32

Heavy Jib length

m

16 ~ 32

Offset

°

0,  15, 30
